917733-1
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER VERT 13POS 2.5MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 917733-1 Datasheet
-
ECAD Model
- Share
In Stock: 158
Can ship immediately
Pricing:
- 1$2
- 10$1.82698
- 100$1.58623
- 500$1.3448
- 1,000$1.17238
- 5,000$1.05514
- 10,000$1.03446
Quote It
Technical Details
- Series:Signal Double Lock
- Package:Bulk
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.098" (2.50mm)
- Number of Positions:13
- Number of Rows:1
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole
- Termination:Kinked Pin, Solder
- Fastening Type:Latch Holder
- Contact Length - Mating:0.185" (4.70mm)
- Contact Length - Post:0.126" (3.20mm)
- Overall Contact Length:0.626" (15.90mm)
- Insulation Height:0.602" (15.29mm)
- Contact Shape:Square
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Tin
- Contact Material:Copper Alloy
- Insulation Material:Polyamide (PA66), Nylon 6/6, Glass Filled
- Features:Board Guide
- Operating Temperature:-30°C ~ 105°C
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Insulation Color:Natural
- Current Rating (Amps):3A
- Voltage Rating:50V
