1-2271457-6
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER R/A 6POS 7.5MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 1-2271457-6 Datasheet
-
ECAD Model
- Share
In Stock: 191
Can ship immediately
Pricing:
- 1$3.82
- 50$3.2519
- 100$3.11039
- 500$2.68628
- 1,000$2.33283
- 5,000$2.12076
Quote It
Technical Details
- Series:Dynamic D-3950
- Package:Tray
- Part Status:Active
- Connector Type:Plug
- Contact Type:Tab
- Pitch - Mating:0.295" (7.50mm)
- Number of Positions:6
- Number of Rows:1
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole, Right Angle
- Termination:Solder
- Fastening Type:Latch Holder
- Contact Length - Mating:-
- Contact Length - Post:-
- Overall Contact Length:-
- Insulation Height:0.472" (12.00mm)
- Contact Shape:Rectangular
- Contact Finish - Mating:Gold
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Tin
- Contact Material:Copper Alloy
- Insulation Material:Thermoplastic
- Features:Board Lock
- Operating Temperature:-30°C ~ 105°C
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Insulation Color:-
- Current Rating (Amps):14.5A
- Voltage Rating:600VAC
