FI-S10P-HFE
JAE Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER SMD R/A 10POS 1.25MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet FI-S10P-HFE Datasheet
-
ECAD Model
- Share
In Stock: 554
Can ship immediately
Pricing:
- 1$2.62
- 10$2.37924
- 100$2.03935
- 500$1.69946
- 1,000$1.45668
- 5,000$1.29159
Quote It
Technical Details
- Series:FI
- Package:Strip
- Part Status:Active
- Connector Type:Receptacle
- Contact Type:Male Pin
- Pitch - Mating:0.049" (1.25mm)
- Number of Positions:10
- Number of Rows:1
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Surface Mount, Right Angle
- Termination:Solder
- Fastening Type:Friction Lock
- Contact Length - Mating:-
- Contact Length - Post:-
- Overall Contact Length:-
- Insulation Height:0.071" (1.80mm)
- Contact Shape:Circular
- Contact Finish - Mating:Gold
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Tin or Tin-Alloy
- Contact Material:Copper Alloy
- Insulation Material:Liquid Crystal Polymer (LCP), Glass Filled
- Features:Solder Retention
- Operating Temperature:-40°C ~ 80°C
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Insulation Color:Beige
- Current Rating (Amps):1A per Contact
- Voltage Rating:200V
