1-776267-1
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER R/A 14POS 4MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 1-776267-1 Datasheet
-
ECAD Model
- Share
In Stock: 189
Can ship immediately
Pricing:
- 1$11.93
- 36$10.44138
- 108$9.44693
- 504$7.95527
- 1,008$6.96086
Quote It
Technical Details
- Series:AMPSEAL
- Package:Bulk
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.157" (4.00mm)
- Number of Positions:14
- Number of Rows:3
- Row Spacing - Mating:0.157" (4.00mm)
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Panel Mount, Through Hole, Right Angle
- Termination:Solder
- Fastening Type:Locking Ramp
- Contact Length - Mating:-
- Contact Length - Post:-
- Overall Contact Length:-
- Insulation Height:-
- Contact Shape:Circular
- Contact Finish - Mating:Gold-Palladium
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:-
- Contact Material:Brass
- Insulation Material:Polybutylene Terephthalate (PBT), Glass Filled
- Features:Board Guide, Sealed
- Operating Temperature:-40°C ~ 125°C
- Ingress Protection:-
- Material Flammability Rating:-
- Insulation Color:Black
- Current Rating (Amps):Varies by Wire Gauge
- Voltage Rating:250VAC
