560-002-420-301
EDAC Inc.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER VERT 2POS 2.5MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 560-002-420-301 Datasheet
-
ECAD Model
- Share
In Stock: 387
Can ship immediately
Pricing:
- 1$1.49
- 10$1.348
- 25$1.2652
- 50$1.21
- 100$1.155
- 250$1.045
- 500$0.9625
- 1,000$0.825
- 2,500$0.77
Quote It
Technical Details
- Series:560
- Package:Bulk
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.098" (2.50mm)
- Number of Positions:2
- Number of Rows:1
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole
- Termination:Solder
- Fastening Type:Latch Holder
- Contact Length - Mating:-
- Contact Length - Post:-
- Overall Contact Length:-
- Insulation Height:0.610" (15.49mm)
- Contact Shape:Circular
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Tin
- Contact Material:Brass
- Insulation Material:Polybutylene Terephthalate (PBT)
- Features:-
- Operating Temperature:-40°C ~ 105°C
- Ingress Protection:IP67
- Material Flammability Rating:UL94 V-0
- Insulation Color:Blue
- Current Rating (Amps):3A
- Voltage Rating:250V
