MX34007UF1
JAE Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER VERT 7POS 2.2MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet MX34007UF1 Datasheet
-
ECAD Model
- Share
In Stock: 212
Can ship immediately
Pricing:
- 1$2.08
- 10$1.887
- 25$1.7712
- 50$1.694
- 100$1.617
- 250$1.463
- 500$1.3475
- 1,000$1.155
- 2,500$1.078
Quote It
Technical Details
- Series:MX34
- Package:Bulk
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.087" (2.20mm)
- Number of Positions:7
- Number of Rows:1
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole
- Termination:Solder
- Fastening Type:Locking Ramp
- Contact Length - Mating:0.303" (7.70mm)
- Contact Length - Post:0.126" (3.20mm)
- Overall Contact Length:-
- Insulation Height:0.594" (15.09mm)
- Contact Shape:Square
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Tin
- Contact Material:Brass
- Insulation Material:Syndiotactic Polystyrene (SPS), Glass Filled
- Features:Board Lock
- Operating Temperature:-40°C ~ 85°C
- Ingress Protection:-
- Material Flammability Rating:-
- Insulation Color:Gray
- Current Rating (Amps):3A
- Voltage Rating:-
