350714-1
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER VERT 15POS 6.35MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 350714-1 Datasheet
-
ECAD Model
- Share
In Stock: 294
Can ship immediately
Pricing:
- 1$2.46
- 10$2.25155
- 100$1.95407
- 500$1.65674
- 1,000$1.44433
- 5,000$1.2999
Quote It
Technical Details
- Series:Universal MATE-N-LOK
- Package:Bulk
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.250" (6.35mm)
- Number of Positions:15
- Number of Rows:3
- Row Spacing - Mating:0.250" (6.35mm)
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole
- Termination:Solder
- Fastening Type:Locking Ramp
- Contact Length - Mating:-
- Contact Length - Post:0.155" (3.94mm)
- Overall Contact Length:-
- Insulation Height:0.550" (13.97mm)
- Contact Shape:Circular
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Tin
- Contact Material:Phosphor Bronze
- Insulation Material:Polyamide (PA), Nylon
- Features:-
- Operating Temperature:-
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Insulation Color:Natural
- Current Rating (Amps):-
- Voltage Rating:-
