AT04-12PC-BM04
Tuchel / Amphenol
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER VERT 12POS
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet AT04-12PC-BM04 Datasheet
-
ECAD Model
- Share
In Stock: 277
Can ship immediately
Pricing:
- 1$8.9
- 10$8.51304
- 25$7.73913
- 50$7.35217
- 100$7.1587
- 250$6.38478
- 500$5.99783
- 1,000$5.3013
Quote It
Technical Details
- Series:BoardLock™ AT
- Package:Tray
- Part Status:Active
- Connector Type:Receptacle
- Contact Type:Male Pin
- Pitch - Mating:-
- Number of Positions:12
- Number of Rows:2
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole
- Termination:Solder
- Fastening Type:Latch Holder
- Contact Length - Mating:-
- Contact Length - Post:-
- Overall Contact Length:-
- Insulation Height:0.835" (21.21mm)
- Contact Shape:Circular
- Contact Finish - Mating:Nickel
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:-
- Contact Material:Copper Alloy
- Insulation Material:Thermoplastic
- Features:Board Lock, Potting Wall
- Operating Temperature:-55°C ~ 125°C
- Ingress Protection:IP67
- Material Flammability Rating:-
- Insulation Color:Green
- Current Rating (Amps):13A
- Voltage Rating:-
