G125-MV11605M3P
Harwin
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER VERT 16POS 1.25MM
- CategoryRectangular Connectors - Headers, Male Pins
-
ECAD Model
- Share
In Stock: 224
Can ship immediately
Pricing:
- 1$14.76
- 10$13.41356
- 100$11.40152
- 500$9.72484
- 1,000$8.92002
Quote It
Technical Details
- Series:Gecko SL Reverse Fix
- Package:Cut Tape (CT)
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.049" (1.25mm)
- Number of Positions:16
- Number of Rows:2
- Row Spacing - Mating:0.049" (1.25mm)
- Number of Positions Loaded:All
- Style:Board to Board or Cable
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole
- Termination:Solder
- Fastening Type:Screw Lock
- Contact Length - Mating:-
- Contact Length - Post:0.118" (3.00mm)
- Overall Contact Length:-
- Insulation Height:0.193" (4.90mm)
- Contact Shape:Circular
- Contact Finish - Mating:Gold
- Contact Finish Thickness - Mating:8.00µin (0.203µm)
- Contact Finish - Post:Gold
- Contact Material:Phosphor Bronze
- Insulation Material:Polyamide (PA4T), Nylon 4T, Glass Filled, Halogen Free
- Features:Mating Flange, Mounting Flange, Pick and Place
- Operating Temperature:-65°C ~ 150°C
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Insulation Color:Green
- Current Rating (Amps):2A
- Voltage Rating:450V
