M80-5000000M7-02-334-00-000
Harwin
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER R/A 2POS 4MM
- CategoryRectangular Connectors - Headers, Male Pins
-
ECAD Model
- Share
In Stock: 174
Can ship immediately
Pricing:
- 1$34.67
- 14$31.29571
- 112$27.17304
Quote It
Technical Details
- Series:Datamate Mix-Tek
- Package:Tube
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin, Power
- Pitch - Mating:0.157" (4.00mm)
- Number of Positions:2
- Number of Rows:1
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole, Right Angle
- Termination:Solder
- Fastening Type:Threaded
- Contact Length - Mating:-
- Contact Length - Post:0.197" (5.00mm)
- Overall Contact Length:-
- Insulation Height:0.236" (6.00mm)
- Contact Shape:Circular
- Contact Finish - Mating:Gold
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Gold
- Contact Material:Copper Alloy
- Insulation Material:Polyphenylene Sulfide (PPS), Glass Filled
- Features:Keying Slot, Mating Flange, Mounting Flange, Mounting Hardware
- Operating Temperature:-55°C ~ 125°C
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Insulation Color:Black
- Current Rating (Amps):20A
- Voltage Rating:800V
