0367720003
Woodhead - Molex
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER VERT 3POS 3.96MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 0367720003 Datasheet
-
ECAD Model
- Share
In Stock: 827
Can ship immediately
Pricing:
- 1$0.45
- 10$0.42955
- 25$0.36818
- 50$0.31295
- 100$0.30068
- 250$0.27
- 500$0.25773
- 1,000$0.21477
- 3,000$0.19636
Quote It
Technical Details
- Series:KK396, 36772
- Package:Tray
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.156" (3.96mm)
- Number of Positions:3
- Number of Rows:1
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 1 Wall
- Mounting Type:Through Hole
- Termination:Solder
- Fastening Type:Friction Lock
- Contact Length - Mating:0.450" (11.43mm)
- Contact Length - Post:0.170" (4.32mm)
- Overall Contact Length:0.750" (19.05mm)
- Insulation Height:0.446" (11.33mm)
- Contact Shape:Square
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:100.0µin (2.54µm)
- Contact Finish - Post:Tin
- Contact Material:-
- Insulation Material:Polyester, Glass Filled
- Features:-
- Operating Temperature:-
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Insulation Color:Natural
- Current Rating (Amps):-
- Voltage Rating:-
