SMS2RE4TR29
Souriau-Sunbank by Eaton
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER VERT 2POS 5.08MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet SMS2RE4TR29 Datasheet
-
ECAD Model
- Share
In Stock: 227
Can ship immediately
Pricing:
- 1$3.1
- 10$2.976
- 100$2.48
- 500$2.108
- 1,000$1.798
- 5,000$1.612
Quote It
Technical Details
- Series:SMS
- Package:Bulk
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.200" (5.08mm)
- Number of Positions:2
- Number of Rows:1
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Unshrouded
- Mounting Type:Through Hole
- Termination:Solder
- Fastening Type:Locking Ramp
- Contact Length - Mating:0.280" (7.11mm)
- Contact Length - Post:0.173" (4.40mm)
- Overall Contact Length:0.972" (24.70mm)
- Insulation Height:0.520" (13.20mm)
- Contact Shape:Circular
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:118.1µin (3.00µm)
- Contact Finish - Post:Tin
- Contact Material:Copper Alloy
- Insulation Material:Polyester, Glass Filled
- Features:Mounting Flange
- Operating Temperature:-55°C ~ 125°C
- Ingress Protection:IP40
- Material Flammability Rating:UL94 V-0
- Insulation Color:Black
- Current Rating (Amps):5A
- Voltage Rating:-
