ATF13-2P-BM01

Technical Details

• Series:BoardLock™ AT
• Package:Bulk
• Part Status:Active
• Connector Type:Receptacle
• Contact Type:Male Pin
• Pitch - Mating:0.213" (5.40mm)
• Number of Positions:2
• Number of Rows:1
• Row Spacing - Mating:-
• Number of Positions Loaded:All
• Style:Board to Cable/Wire
• Shrouding:Shrouded - 4 Wall
• Mounting Type:Through Hole, Right Angle
• Termination:Solder
• Fastening Type:Latch Holder
• Contact Length - Mating:-

• Contact Length - Post:0.120" (3.05mm)
• Overall Contact Length:-
• Insulation Height:0.709" (18.00mm)
• Contact Shape:Circular
• Contact Finish - Mating:Gold
• Contact Finish Thickness - Mating:-
• Contact Finish - Post:Gold
• Contact Material:Copper Alloy
• Insulation Material:Thermoplastic
• Features:Board Lock
• Operating Temperature:-55°C ~ 125°C
• Ingress Protection:IP67 - Dust Tight, Waterproof
• Material Flammability Rating:-
• Insulation Color:Black
• Current Rating (Amps):13A
• Voltage Rating:250VDC
