BM02B-NSHSS-TBT(LF)(SN)
JST
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER SMD 2POS 1MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet BM02B-NSHSS-TBT(LF)(SN) Datasheet
-
ECAD Model
- Share
In Stock: 2,776
Can ship immediately
Pricing:
- 1$0.81
- 1,000$0.41817
- 2,000$0.4055
- 3,000$0.38016
- 5,000$0.36749
- 10,000$0.34214
- 25,000$0.32947
Quote It
Technical Details
- Series:NSH
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.039" (1.00mm)
- Number of Positions:2
- Number of Rows:1
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Surface Mount
- Termination:Solder
- Fastening Type:Latch Holder
- Contact Length - Mating:-
- Contact Length - Post:-
- Overall Contact Length:-
- Insulation Height:0.236" (6.00mm)
- Contact Shape:-
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Tin
- Contact Material:Copper Alloy
- Insulation Material:Polyamide (PA), Nylon
- Features:Pick and Place Cap, Solder Retention
- Operating Temperature:-25°C ~ 85°C
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Insulation Color:Natural
- Current Rating (Amps):1A
- Voltage Rating:50V
