951136-8622-AR
3M
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER VERT 36POS 2MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 951136-8622-AR Datasheet
-
ECAD Model
- Share
In Stock: 259
Can ship immediately
Pricing:
- 1$2.54
- 10$2.307
- 25$2.166
- 50$2.0718
- 100$1.9777
- 250$1.78936
- 500$1.64808
Quote It
Technical Details
- Series:951
- Package:Bulk
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.079" (2.00mm)
- Number of Positions:36
- Number of Rows:1
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Board
- Shrouding:Unshrouded
- Mounting Type:Through Hole
- Termination:Solder
- Fastening Type:Push-Pull
- Contact Length - Mating:0.173" (4.40mm)
- Contact Length - Post:0.110" (2.79mm)
- Overall Contact Length:0.343" (8.70mm)
- Insulation Height:0.060" (1.52mm)
- Contact Shape:Square
- Contact Finish - Mating:Gold
- Contact Finish Thickness - Mating:Flash
- Contact Finish - Post:Tin
- Contact Material:Copper Alloy
- Insulation Material:Thermoplastic
- Features:-
- Operating Temperature:-55°C ~ 125°C
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Insulation Color:Black
- Current Rating (Amps):1A
- Voltage Rating:-
