- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER R/A 12POS
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet DTM13-12PA-R008 Datasheet
-
ECAD Model
- Share
In Stock: 116
Can ship immediately
Pricing:
- 1$18.66
- 10$17.33102
- 25$15.55306
- 50$15.10858
- 100$13.3311
- 250$12.44236
- 500$12.17574
- 1,000$11.55362
Quote It
Technical Details
- Series:DTM
- Package:Bulk
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:-
- Number of Positions:12
- Number of Rows:2
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Panel Mount, Through Hole, Right Angle
- Termination:Solder
- Fastening Type:Latch Holder
- Contact Length - Mating:-
- Contact Length - Post:0.112" (2.84mm)
- Overall Contact Length:-
- Insulation Height:1.378" (35.00mm)
- Contact Shape:Circular
- Contact Finish - Mating:Nickel
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Tin
- Contact Material:-
- Insulation Material:Plastic
- Features:Mounting Flange
- Operating Temperature:-
- Ingress Protection:IP68/IP6K9K
- Material Flammability Rating:-
- Insulation Color:Black
- Current Rating (Amps):-
- Voltage Rating:-
