1877285-4
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER VERT 4POS 3.96MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 1877285-4 Datasheet
-
ECAD Model
- Share
In Stock: 153
Can ship immediately
Pricing:
- 1$0.42
- 10$0.40425
- 100$0.28936
- 500$0.25111
- 1,000$0.21289
- 5,000$0.1856
- 10,000$0.17468
Quote It
Technical Details
- Series:Economy Power
- Package:Bulk
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.156" (3.96mm)
- Number of Positions:4
- Number of Rows:1
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole
- Termination:Solder
- Fastening Type:Friction Lock
- Contact Length - Mating:0.306" (7.77mm)
- Contact Length - Post:0.142" (3.60mm)
- Overall Contact Length:0.567" (14.40mm)
- Insulation Height:0.472" (12.00mm)
- Contact Shape:Square
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:39.4µin (1.00µm)
- Contact Finish - Post:Tin
- Contact Material:Brass
- Insulation Material:Polybutylene Terephthalate (PBT), Glass Filled
- Features:Board Guide
- Operating Temperature:-25°C ~ 105°C
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Insulation Color:White
- Current Rating (Amps):7.5A
- Voltage Rating:250VAC
