1-967280-1
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER R/A 42POS 5MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 1-967280-1 Datasheet
-
ECAD Model
- Share
In Stock: 171
Can ship immediately
Pricing:
- 1$20.97
- 10$19.46705
- 100$14.97417
- 500$13.67645
Quote It
Technical Details
- Series:Junior Power Timer
- Package:Tray
- Part Status:Active
- Connector Type:Plug
- Contact Type:Tab
- Pitch - Mating:0.197" (5.00mm)
- Number of Positions:42
- Number of Rows:3
- Row Spacing - Mating:0.230" (5.84mm)
- Number of Positions Loaded:All
- Style:Board to Board or Cable
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole, Right Angle
- Termination:Solder
- Fastening Type:Lever Lock
- Contact Length - Mating:0.315" (8.00mm)
- Contact Length - Post:0.122" (3.10mm)
- Overall Contact Length:-
- Insulation Height:1.280" (32.50mm)
- Contact Shape:Rectangular
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Tin
- Contact Material:Copper Alloy
- Insulation Material:Polybutylene Terephthalate (PBT), Glass Filled
- Features:Mounting Flange
- Operating Temperature:-
- Ingress Protection:-
- Material Flammability Rating:-
- Insulation Color:Black
- Current Rating (Amps):-
- Voltage Rating:-
