2-1123723-4
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER VERT 4POS 3.96MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 2-1123723-4 Datasheet
-
ECAD Model
- Share
In Stock: 155
Can ship immediately
Pricing:
- 1$0.27
- 10$0.261
- 25$0.2256
- 50$0.1942
- 100$0.1869
- 250$0.16932
- 500$0.16228
- 1,000$0.13757
- 2,500$0.12699
Quote It
Technical Details
- Series:Economy Power
- Package:Bulk
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.156" (3.96mm)
- Number of Positions:4
- Number of Rows:1
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 1 Wall
- Mounting Type:Through Hole
- Termination:Solder
- Fastening Type:Friction Lock
- Contact Length - Mating:0.303" (7.70mm)
- Contact Length - Post:0.146" (3.70mm)
- Overall Contact Length:0.567" (14.40mm)
- Insulation Height:0.118" (3.00mm)
- Contact Shape:Square
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Tin
- Contact Material:Brass
- Insulation Material:Polybutylene Terephthalate (PBT), Glass Filled
- Features:-
- Operating Temperature:-25°C ~ 105°C
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Insulation Color:Yellow
- Current Rating (Amps):7.5A
- Voltage Rating:250VAC
