KA1-MV10305M1
Harwin
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HDR 8.5MM VERT PCB 3POS
- CategoryRectangular Connectors - Headers, Male Pins
-
ECAD Model
- Share
In Stock: 144
Can ship immediately
Pricing:
- 1$40.59
Quote It
Technical Details
- Series:KONA
- Package:Tube
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin, Power
- Pitch - Mating:0.335" (8.50mm)
- Number of Positions:3
- Number of Rows:1
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Board or Cable
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole
- Termination:Solder
- Fastening Type:Threaded
- Contact Length - Mating:-
- Contact Length - Post:0.177" (4.50mm)
- Overall Contact Length:-
- Insulation Height:0.374" (9.50mm)
- Contact Shape:Circular
- Contact Finish - Mating:Gold
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Gold
- Contact Material:Beryllium Copper
- Insulation Material:Polyphenylene Sulfide (PPS)
- Features:Mating Flange, Mounting Flange
- Operating Temperature:-65°C ~ 150°C
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Insulation Color:Black
- Current Rating (Amps):60A per Contact
- Voltage Rating:-
