4-1971906-2
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER VERT 4POS 3.3MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 4-1971906-2 Datasheet
-
ECAD Model
- Share
In Stock: 165
Can ship immediately
Pricing:
- 1$0.11821
- 10$0.11304
- 25$0.09708
- 50$0.08245
- 100$0.07924
- 425$0.07116
- 850$0.05984
- 1,275$0.0566
- 2,550$0.05175
Quote It
Technical Details
- Series:Grace Inertia, GIC
- Package:Tray
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.130" (3.30mm)
- Number of Positions:4
- Number of Rows:2
- Row Spacing - Mating:0.205" (5.20mm)
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole
- Termination:Kinked Pin, Solder
- Fastening Type:Latch Holder
- Contact Length - Mating:-
- Contact Length - Post:0.118" (3.00mm)
- Overall Contact Length:0.575" (14.60mm)
- Insulation Height:0.561" (14.25mm)
- Contact Shape:Square
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Tin
- Contact Material:Brass
- Insulation Material:Polyamide (PA66), Nylon 6/6, Glass Filled
- Features:Board Guide
- Operating Temperature:-30°C ~ 105°C
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Insulation Color:Yellow
- Current Rating (Amps):Varies by Wire Gauge
- Voltage Rating:250VAC
