008263061200002+

Technical Details

• Series:8263, Kyocera
• Package:Bag
• Part Status:Active
• Connector Type:Header
• Contact Type:Male Pin
• Pitch - Mating:0.098" (2.50mm)
• Number of Positions:6
• Number of Rows:1
• Row Spacing - Mating:-
• Number of Positions Loaded:All
• Style:Board to Cable/Wire
• Shrouding:Shrouded - 1 Wall
• Mounting Type:Through Hole
• Termination:Solder
• Fastening Type:Push-Pull
• Contact Length - Mating:0.217" (5.50mm)

• Contact Length - Post:0.142" (3.60mm)
• Overall Contact Length:0.437" (11.10mm)
• Insulation Height:0.346" (8.80mm)
• Contact Shape:Square
• Contact Finish - Mating:-
• Contact Finish Thickness - Mating:-
• Contact Finish - Post:-
• Contact Material:Copper Alloy
• Insulation Material:Thermoplastic
• Features:-
• Operating Temperature:-20°C ~ 85°C
• Ingress Protection:-
• Material Flammability Rating:-
• Insulation Color:Red
• Current Rating (Amps):3A per Contact
• Voltage Rating:250VDC
