5-2232001-2

Technical Details

• Series:-
• Package:Bulk
• Part Status:Active
• Connector Type:Header
• Contact Type:Tab
• Pitch - Mating:0.197" (5.00mm)
• Number of Positions:2
• Number of Rows:1
• Row Spacing - Mating:-
• Number of Positions Loaded:All
• Style:Board to Cable/Wire
• Shrouding:Shrouded - 4 Wall
• Mounting Type:Through Hole
• Termination:Solder
• Fastening Type:Latch Holder
• Contact Length - Mating:-

• Contact Length - Post:0.138" (3.50mm)
• Overall Contact Length:-
• Insulation Height:0.504" (12.80mm)
• Contact Shape:Rectangular
• Contact Finish - Mating:Silver
• Contact Finish Thickness - Mating:-
• Contact Finish - Post:Silver
• Contact Material:Copper Alloy
• Insulation Material:Polyamide (PA), Nylon
• Features:Board Guide, Glow Wire Compliant
• Operating Temperature:-40°C ~ 120°C
• Ingress Protection:-
• Material Flammability Rating:UL94 V-0
• Insulation Color:Black
• Current Rating (Amps):20A
• Voltage Rating:250VAC
