008283111200000+
KYOCERA Corporation- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionWIRE TO BOARD
- CategoryRectangular Connectors - Headers, Male Pins
-
ECAD Model
- Share
In Stock: 172
Can ship immediately
Pricing:
- 1$0.47372
Quote It
Technical Details
- Series:8283, Kyocera
- Package:Bag
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.079" (2.00mm)
- Number of Positions:11
- Number of Rows:1
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 3 Wall
- Mounting Type:Through Hole
- Termination:Kinked Pin, Solder
- Fastening Type:Detent Lock
- Contact Length - Mating:0.185" (4.70mm)
- Contact Length - Post:0.118" (3.00mm)
- Overall Contact Length:0.370" (9.40mm)
- Insulation Height:0.268" (6.80mm)
- Contact Shape:Circular
- Contact Finish - Mating:-
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:-
- Contact Material:Copper Alloy
- Insulation Material:Thermoplastic
- Features:-
- Operating Temperature:-
- Ingress Protection:-
- Material Flammability Rating:-
- Insulation Color:Natural
- Current Rating (Amps):-
- Voltage Rating:-
