008283141100001+

Technical Details

• Series:8283, Kyocera
• Package:Bag
• Part Status:Active
• Connector Type:Header
• Contact Type:Male Pin
• Pitch - Mating:0.079" (2.00mm)
• Number of Positions:14
• Number of Rows:1
• Row Spacing - Mating:-
• Number of Positions Loaded:All
• Style:Board to Cable/Wire
• Shrouding:Shrouded - 3 Wall
• Mounting Type:Through Hole, Right Angle
• Termination:Kinked Pin, Solder
• Fastening Type:Detent Lock
• Contact Length - Mating:0.185" (4.70mm)

• Contact Length - Post:0.118" (3.00mm)
• Overall Contact Length:-
• Insulation Height:0.157" (4.00mm)
• Contact Shape:Circular
• Contact Finish - Mating:-
• Contact Finish Thickness - Mating:-
• Contact Finish - Post:-
• Contact Material:Copper Alloy
• Insulation Material:Thermoplastic
• Features:-
• Operating Temperature:-
• Ingress Protection:-
• Material Flammability Rating:-
• Insulation Color:Black
• Current Rating (Amps):-
• Voltage Rating:-
