3-1971896-3
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER VERT 3POS 5MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 3-1971896-3 Datasheet
-
ECAD Model
- Share
In Stock: 137
Can ship immediately
Pricing:
- 1$0.63374
- 4,000$0.60936
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Connector Type:Header
- Contact Type:Tab
- Pitch - Mating:0.197" (5.00mm)
- Number of Positions:3
- Number of Rows:1
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole
- Termination:Solder
- Fastening Type:Latch Holder
- Contact Length - Mating:-
- Contact Length - Post:0.138" (3.50mm)
- Overall Contact Length:-
- Insulation Height:0.504" (12.80mm)
- Contact Shape:Rectangular
- Contact Finish - Mating:Silver
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Silver
- Contact Material:Copper Alloy
- Insulation Material:Polyamide (PA), Nylon
- Features:Board Guide, Glow Wire Compliant
- Operating Temperature:-40°C ~ 120°C
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Insulation Color:Natural
- Current Rating (Amps):20A
- Voltage Rating:250VAC
