9-176314-0
TE Connectivity AMP Connectors- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER SMD 30POS 1.25MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 9-176314-0 Datasheet
-
ECAD Model
- Share
In Stock: 144
Can ship immediately
Pricing:
- 1$0.6801
- 8,000$0.65694
Quote It
Technical Details
- Series:Fine Pitch
- Package:Tube
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.049" (1.25mm)
- Number of Positions:30
- Number of Rows:2
- Row Spacing - Mating:0.049" (1.25mm)
- Number of Positions Loaded:All
- Style:Board to Board
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Surface Mount
- Termination:Solder
- Fastening Type:Push-Pull
- Contact Length - Mating:-
- Contact Length - Post:-
- Overall Contact Length:-
- Insulation Height:0.156" (3.96mm)
- Contact Shape:Circular
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:31.5µin (0.80µm)
- Contact Finish - Post:Tin
- Contact Material:Brass
- Insulation Material:Polyphenylene Sulfide (PPS)
- Features:Board Guide
- Operating Temperature:-30°C ~ 105°C
- Ingress Protection:-
- Material Flammability Rating:-
- Insulation Color:Black
- Current Rating (Amps):0.5A
- Voltage Rating:50V
