IL-WX-14PB-VF-B-E1000E

JAE Electronics
In Stock: 170

Can ship immediately

Pricing:
  • 1$0.7768
  • 1,000$0.7768

Quote It

Technical Details

  • Series:IL-WX
  • Package:Tape & Reel (TR)
  • Part Status:Active
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.031" (0.80mm)
  • Number of Positions:14
  • Number of Rows:2
  • Row Spacing - Mating:0.059" (1.50mm)
  • Number of Positions Loaded:All
  • Style:Board to Board
  • Shrouding:Shrouded - 4 Wall
  • Mounting Type:Surface Mount
  • Termination:Solder
  • Fastening Type:Push-Pull
  • Contact Length - Mating:0.071" (1.80mm)



  • Contact Length - Post:-
  • Overall Contact Length:-
  • Insulation Height:0.144" (3.66mm)
  • Contact Shape:Square
  • Contact Finish - Mating:Tin
  • Contact Finish Thickness - Mating:-
  • Contact Finish - Post:Tin
  • Contact Material:Brass
  • Insulation Material:Polyphenylene Sulfide (PPS)
  • Features:Board Guide, Solder Retention
  • Operating Temperature:-40°C ~ 85°C
  • Ingress Protection:-
  • Material Flammability Rating:-
  • Insulation Color:Black
  • Current Rating (Amps):0.5A per Contact
  • Voltage Rating:-
