0367831202
Woodhead - Molex- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER R/A 12POS 3.2MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 0367831202 Datasheet
-
ECAD Model
- Share
In Stock: 121
Can ship immediately
Pricing:
- 1$0.81158
- 1,680$0.81158
Quote It
Technical Details
- Series:MX120G 36783
- Package:Bulk
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.126" (3.20mm)
- Number of Positions:12
- Number of Rows:2
- Row Spacing - Mating:0.233" (5.93mm)
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Panel Mount, Through Hole, Right Angle
- Termination:Solder
- Fastening Type:Locking Ramp
- Contact Length - Mating:-
- Contact Length - Post:-
- Overall Contact Length:-
- Insulation Height:0.649" (16.49mm)
- Contact Shape:Square
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:39.4µin (1.00µm)
- Contact Finish - Post:Tin
- Contact Material:Brass
- Insulation Material:Polyamide (PA), Nylon, Glass Filled
- Features:Board Lock
- Operating Temperature:-
- Ingress Protection:IP67 - Dust Tight, Waterproof
- Material Flammability Rating:UL94 HB
- Insulation Color:Black
- Current Rating (Amps):-
- Voltage Rating:-
