0908143222
Woodhead - Molex
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER SMD 22POS 1.27MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 0908143222 Datasheet
-
ECAD Model
- Share
In Stock: 195
Can ship immediately
Pricing:
- 1$0.9713
- 6,000$0.9713
Quote It
Technical Details
- Series:Picoflex PF-50 90814
- Package:Tape & Reel (TR)
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Blade
- Pitch - Mating:0.050" (1.27mm)
- Number of Positions:22
- Number of Rows:1
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 2 Wall
- Mounting Type:Surface Mount
- Termination:Solder
- Fastening Type:Push-Pull
- Contact Length - Mating:0.085" (2.15mm)
- Contact Length - Post:-
- Overall Contact Length:-
- Insulation Height:0.252" (6.40mm)
- Contact Shape:Rectangular
- Contact Finish - Mating:Palladium-Nickel
- Contact Finish Thickness - Mating:24.0µin (0.61µm)
- Contact Finish - Post:Tin
- Contact Material:Cartridge Brass
- Insulation Material:Polyamide (PA), Nylon, Glass Filled
- Features:Board Guide
- Operating Temperature:-
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Insulation Color:Natural
- Current Rating (Amps):1.2A
- Voltage Rating:250V
