IL-WX-24PB-VF-B-E1000E

Technical Details

• Series:IL-WX
• Package:Tape & Reel (TR)
• Part Status:Active
• Connector Type:Header
• Contact Type:Male Pin
• Pitch - Mating:0.031" (0.80mm)
• Number of Positions:24
• Number of Rows:2
• Row Spacing - Mating:0.059" (1.50mm)
• Number of Positions Loaded:All
• Style:Board to Board
• Shrouding:Shrouded - 4 Wall
• Mounting Type:Surface Mount
• Termination:Solder
• Fastening Type:Push-Pull
• Contact Length - Mating:0.071" (1.80mm)

• Contact Length - Post:-
• Overall Contact Length:-
• Insulation Height:0.144" (3.66mm)
• Contact Shape:Square
• Contact Finish - Mating:Tin
• Contact Finish Thickness - Mating:-
• Contact Finish - Post:Tin
• Contact Material:Brass
• Insulation Material:Polyphenylene Sulfide (PPS)
• Features:Board Guide, Solder Retention
• Operating Temperature:-40°C ~ 85°C
• Ingress Protection:-
• Material Flammability Rating:-
• Insulation Color:Black
• Current Rating (Amps):0.5A per Contact
• Voltage Rating:-
