1-174954-1
TE Connectivity AMP Connectors- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER VERT 6POS 3.5MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 1-174954-1 Datasheet
-
ECAD Model
- Share
In Stock: 130
Can ship immediately
Pricing:
- 1$1.04909
- 4,000$0.99914
Quote It
Technical Details
- Series:Multi-Lock
- Package:Tube
- Part Status:Active
- Connector Type:-
- Contact Type:Tab
- Pitch - Mating:0.138" (3.50mm)
- Number of Positions:6
- Number of Rows:1
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole
- Termination:Solder
- Fastening Type:Latch Holder
- Contact Length - Mating:-
- Contact Length - Post:0.157" (4.00mm)
- Overall Contact Length:-
- Insulation Height:0.925" (23.50mm)
- Contact Shape:Rectangular
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Tin
- Contact Material:Brass
- Insulation Material:Polybutylene Terephthalate (PBT)
- Features:Mounting Brackets
- Operating Temperature:-30°C ~ 105°C
- Ingress Protection:-
- Material Flammability Rating:-
- Insulation Color:White
- Current Rating (Amps):Varies by Wire Gauge
- Voltage Rating:-
