In Stock: 194

Can ship immediately

Pricing:
  • 1$1.17048
  • 896$1.17048

Quote It

Technical Details

  • Series:Micro MATE-N-LOK
  • Package:Tray
  • Part Status:Active
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.118" (3.00mm)
  • Number of Positions:9
  • Number of Rows:1
  • Row Spacing - Mating:-
  • Number of Positions Loaded:All
  • Style:Board to Cable/Wire
  • Shrouding:Shrouded - 4 Wall
  • Mounting Type:Through Hole, Right Angle
  • Termination:Solder
  • Fastening Type:Locking Ramp
  • Contact Length - Mating:-



  • Contact Length - Post:0.138" (3.50mm)
  • Overall Contact Length:-
  • Insulation Height:0.152" (3.85mm)
  • Contact Shape:Square
  • Contact Finish - Mating:Gold
  • Contact Finish Thickness - Mating:15.0µin (0.38µm)
  • Contact Finish - Post:Tin
  • Contact Material:Brass
  • Insulation Material:Polyamide (PA), Nylon
  • Features:Board Lock
  • Operating Temperature:-40°C ~ 105°C
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Black
  • Current Rating (Amps):Varies by Wire Gauge
  • Voltage Rating:250V

Related Products


894-70-033-10-001101

CONN HEADER VERT 33POS 2.54MM

894-70-033-10-001101 Datasheet
  • 1: $1.17059
  • 460: $1.06139

1-644749-7

CONN HEADER VERT 17POS 3.96MM

1-644749-7 Datasheet
  • 1: $1.17084
  • 500: $1.11508

2-644750-0

CONN HEADER VERT 20POS 3.96MM

2-644750-0 Datasheet
  • 1: $1.17084
  • 500: $1.11508

351-10-109-00-003101

CONN HEADER VERT 9POS 2.54MM

351-10-109-00-003101 Datasheet
  • 1: $1.17092
  • 500: $1.02286

0022283181

CONN HEADER VERT 18POS 2.54MM

0022283181 Datasheet
  • 1: $1.17096
  • 2500: $1.17096

0022283187

CONN HEADER VERT 18POS 2.54MM

0022283187 Datasheet
  • 1: $1.17096
  • 2500: $1.17096

0878331260

CONN HEADER R/A 12POS 2MM

0878331260 Datasheet
  • 1: $1.17117

829487-7

CONN HEADER VERT 7POS 2.54MM

829487-7 Datasheet
  • 1: $1.17126
  • 4800: $1.17126

68023-236HLF
