850-10-011-40-251191

Preci-Dip
In Stock: 144

Can ship immediately

Pricing:
  • 1$1.17811
  • 2,000$1.17811

Quote It

Technical Details

  • Series:850
  • Package:Bulk
  • Part Status:Active
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.050" (1.27mm)
  • Number of Positions:11
  • Number of Rows:1
  • Row Spacing - Mating:-
  • Number of Positions Loaded:All
  • Style:Board to Board
  • Shrouding:Unshrouded
  • Mounting Type:Surface Mount, Right Angle
  • Termination:Solder
  • Fastening Type:Push-Pull
  • Contact Length - Mating:0.118" (3.00mm)



  • Contact Length - Post:-
  • Overall Contact Length:-
  • Insulation Height:0.087" (2.20mm)
  • Contact Shape:Circular
  • Contact Finish - Mating:Gold
  • Contact Finish Thickness - Mating:10.0µin (0.25µm)
  • Contact Finish - Post:Gold
  • Contact Material:Brass
  • Insulation Material:Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
  • Features:-
  • Operating Temperature:-55°C ~ 125°C
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Black
  • Current Rating (Amps):1A
  • Voltage Rating:150VDC

Related Products


10131319-16111G0LF

CONN HEADER VERT 16POS 4.2MM

  • 1: $1.17818
  • 495: $1.17818

87139-013LF

CONN HEADER VERT 20POS 2MM

87139-013LF Datasheet
  • 1: $1.17824
  • 3000: $1.17824

77311-101-29LF

CONN HEADER VERT 29POS 2.54MM

77311-101-29LF Datasheet
  • 1: $1.17838
  • 400: $1.08947

832-10-008-30-001191

CONN HEADER SMD 8POS 2MM

  • 1: $1.17838
  • 600: $1.17838

77313-827-30LF

CONN HEADER VERT 30POS 2.54MM

77313-827-30LF Datasheet
  • 1: $1.17838
  • 400: $1.08947

2-1586842-0

CONN HEADER SMD 20POS 3MM

2-1586842-0 Datasheet
  • 1: $1.17843
  • 4900: $1.17843

75160-101-10LF

CONN HEADER VERT 10POS 2.54MM

75160-101-10LF Datasheet
  • 1: $1.17846
  • 500: $1.08956

0022102112

CONN HEADER VERT 11POS 2.54MM

0022102112 Datasheet
  • 1: $1.17852
  • 4000: $1.17852

0022104108

CONN HEADER VERT 10POS 2.54MM

0022104108 Datasheet
  • 1: $1.17852
  • 4000: $1.17852

882-70-032-10-001101
