008261093313806
KYOCERA Corporation- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER
- CategoryRectangular Connectors - Headers, Male Pins
-
ECAD Model
- Share
In Stock: 154
Can ship immediately
Pricing:
- 1$1.2
Quote It
Technical Details
- Series:8261, Kyocera
- Package:Bag
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.100" (2.54mm)
- Number of Positions:9
- Number of Rows:3
- Row Spacing - Mating:0.100" (2.54mm)
- Number of Positions Loaded:All
- Style:-
- Shrouding:Unshrouded
- Mounting Type:Through Hole
- Termination:Solder
- Fastening Type:Push-Pull
- Contact Length - Mating:0.169" (4.30mm)
- Contact Length - Post:0.126" (3.20mm)
- Overall Contact Length:0.354" (9.00mm)
- Insulation Height:0.059" (1.50mm)
- Contact Shape:Circular
- Contact Finish - Mating:Gold
- Contact Finish Thickness - Mating:3.94µin (0.100µm)
- Contact Finish - Post:Gold
- Contact Material:Copper Alloy
- Insulation Material:Thermoplastic
- Features:-
- Operating Temperature:-55°C ~ 85°C
- Ingress Protection:-
- Material Flammability Rating:-
- Insulation Color:Black
- Current Rating (Amps):3A per Contact
- Voltage Rating:250VAC/DC
