In Stock: 130

Can ship immediately

Pricing:
  • 1$1.28155
  • 400$1.18521

Quote It

Technical Details

  • Series:BERGSTIK®
  • Package:Bag
  • Part Status:Active
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.100" (2.54mm)
  • Number of Positions:31
  • Number of Rows:1
  • Row Spacing - Mating:-
  • Number of Positions Loaded:All
  • Style:Board to Board
  • Shrouding:Unshrouded
  • Mounting Type:Through Hole
  • Termination:Solder
  • Fastening Type:Push-Pull
  • Contact Length - Mating:0.266" (6.75mm)



  • Contact Length - Post:0.114" (2.90mm)
  • Overall Contact Length:0.480" (12.19mm)
  • Insulation Height:0.100" (2.54mm)
  • Contact Shape:Square
  • Contact Finish - Mating:Gold or Gold, GXT™
  • Contact Finish Thickness - Mating:15.0µin (0.38µm)
  • Contact Finish - Post:Tin
  • Contact Material:Phosphor Bronze
  • Insulation Material:Thermoplastic
  • Features:-
  • Operating Temperature:-
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Black
  • Current Rating (Amps):-
  • Voltage Rating:-

Related Products


77315-824-22LF

CONN HEADER R/A 22POS 2.54MM

77315-824-22LF Datasheet
  • 1: $1.28155
  • 400: $1.18521

53612-S10-8LF

CONN HEADER SMD 10POS 2.54MM

  • 1: $1.28155
  • 400: $1.28155

0015916065

CONN HEADER SMD 6POS 2.54MM

0015916065 Datasheet
  • 1: $1.28159
  • 6900: $1.28159

1718574012

CONN HEADER R/A 12POS 2.54MM

1718574012 Datasheet
  • 1: $1.28180
  • 2100: $1.28180

350-10-113-00-006101

CONN HEADER VERT 13POS 2.54MM

350-10-113-00-006101 Datasheet
  • 1: $1.28206
  • 500: $1.11990

0022282284

CONN HEADER R/A 28POS 2.54MM

0022282284 Datasheet
  • 1: $1.28212
  • 2500: $1.28212

800-80-016-30-001101

CONN HEADER SMD 16POS 2.54MM

800-80-016-30-001101 Datasheet
  • 1: $1.28213
  • 800: $1.05646

93689-101-06LF
