0348258126

Woodhead - Molex
In Stock: 166

Can ship immediately

Pricing:
  • 1$1.29761
  • 12,240$0.97275

Quote It

Technical Details

  • Series:Mini50 34825
  • Package:Tape & Reel (TR)
  • Part Status:Active
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.079" (2.00mm)
  • Number of Positions:12
  • Number of Rows:2
  • Row Spacing - Mating:-
  • Number of Positions Loaded:All
  • Style:Board to Cable/Wire
  • Shrouding:Shrouded - 4 Wall
  • Mounting Type:Through Hole
  • Termination:Solder
  • Fastening Type:Latch Holder
  • Contact Length - Mating:0.218" (5.55mm)



  • Contact Length - Post:0.113" (2.87mm)
  • Overall Contact Length:-
  • Insulation Height:0.614" (15.60mm)
  • Contact Shape:Square
  • Contact Finish - Mating:Tin
  • Contact Finish Thickness - Mating:-
  • Contact Finish - Post:Tin
  • Contact Material:Brass
  • Insulation Material:Syndiotactic Polystyrene (SPS), Glass Filled
  • Features:Board Guide, Solder Retention
  • Operating Temperature:-
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Gray
  • Current Rating (Amps):-
  • Voltage Rating:-

Related Products


68020-230HLF

CONN HEADER R/A 30POS 2.54MM

68020-230HLF Datasheet
  • 1: $1.29775
  • 1600: $1.29775

67996-130

CONN HEADER VERT 30POS 2.54MM

67996-130 Datasheet
  • 1: $1.29775
  • 1600: $1.29775

4-794631-0

CONN HEADER VERT 10POS 3MM

4-794631-0 Datasheet
  • 1: $1.29778
  • 2145: $1.29778

0554561869

CONN HEADER SMD R/A 18POS 1.25MM

0554561869 Datasheet
  • 1: $1.29780
  • 3750: $1.29780

1724470012

CONN HEADER VERT 12POS 4.2MM

1724470012 Datasheet
  • 1: $1.29780
  • 2400: $1.29780

1511181138

MGRID SHRD HDR SMT /OPEG&CAP GFL

  • 1: $1.29781

1511181188

MGRID SHRD HDR SMT W/PEG GFLF 38

  • 1: $1.29781

2-2842274-2

22P,2MM,SHRD HDR,DRVT,SMD,0.1AU,

  • 1: $1.29786

10127819-14111PLF

CONN HEADER R/A 14POS 4.2MM

  • 1: $1.29790
  • 390: $1.29790

A1A-16PA-2.54DS(71)
