In Stock: 142

Can ship immediately

Pricing:
  • 1$1.5027
  • 400$1.38928

Quote It

Technical Details

  • Series:BERGSTIK®
  • Package:Bag
  • Part Status:Active
  • Connector Type:Header, Breakaway
  • Contact Type:Male Pin
  • Pitch - Mating:0.100" (2.54mm)
  • Number of Positions:27
  • Number of Rows:1
  • Row Spacing - Mating:-
  • Number of Positions Loaded:All
  • Style:Board to Board
  • Shrouding:Unshrouded
  • Mounting Type:Through Hole, Right Angle
  • Termination:Solder
  • Fastening Type:Push-Pull
  • Contact Length - Mating:0.230" (5.84mm)



  • Contact Length - Post:0.120" (3.05mm)
  • Overall Contact Length:-
  • Insulation Height:0.094" (2.40mm)
  • Contact Shape:Square
  • Contact Finish - Mating:Gold or Gold, GXT™
  • Contact Finish Thickness - Mating:30.0µin (0.76µm)
  • Contact Finish - Post:Tin
  • Contact Material:Phosphor Bronze
  • Insulation Material:Thermoplastic
  • Features:-
  • Operating Temperature:-
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Black
  • Current Rating (Amps):-
  • Voltage Rating:-

Related Products


77315-818-27LF

CONN HEADER R/A 27POS 2.54MM

77315-818-27LF Datasheet
  • 1: $1.50270
  • 400: $1.38928

892-70-058-10-001101

CONN HEADER VERT 58POS 2.54MM

892-70-058-10-001101 Datasheet
  • 1: $1.50272
  • 360: $1.36231

146131-7

CONN HEADER SMD 16POS 2.54MM

146131-7 Datasheet
  • 1: $1.50282
  • 1170: $1.43748

146130-8

CONN HEADER SMD 18POS 2.54MM

146130-8 Datasheet
  • 1: $1.50293
  • 1035: $1.43758

98424-S52-16ALF

CONN HEADER SMD 16POS 2MM

98424-S52-16ALF Datasheet
  • 1: $1.50308
  • 600: $1.38985

2-644753-2

CONN HEADER VERT 22POS 3.96MM

2-644753-2 Datasheet
  • 1: $1.50310
  • 500: $1.43152

2010222116

CONN HEADER VERT 16POS 1.27MM

2010222116 Datasheet
  • 1: $1.50318

0430456225

CONN HEADER VERT 12POS 3MM

0430456225 Datasheet
  • 1: $1.50321
  • 1008: $1.50321

0010977405

CONN HEADER VERT 40POS 2.54MM

0010977405 Datasheet
  • 1: $1.50323
  • 2100: $1.50323

77313-115-32LF
