In Stock: 193

Can ship immediately

Pricing:
  • 1$1.55584

Quote It

Technical Details

  • Series:Minitek® 2.00mm
  • Package:Tape & Reel (TR)
  • Part Status:Active
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.079" (2.00mm)
  • Number of Positions:20
  • Number of Rows:2
  • Row Spacing - Mating:0.079" (2.00mm)
  • Number of Positions Loaded:19
  • Style:Board to Board
  • Shrouding:Unshrouded
  • Mounting Type:Surface Mount
  • Termination:Solder
  • Fastening Type:Push-Pull
  • Contact Length - Mating:0.138" (3.50mm)



  • Contact Length - Post:-
  • Overall Contact Length:-
  • Insulation Height:-
  • Contact Shape:Square
  • Contact Finish - Mating:Gold, GXT™
  • Contact Finish Thickness - Mating:15.0µin (0.38µm)
  • Contact Finish - Post:Tin
  • Contact Material:Copper Alloy
  • Insulation Material:Thermoplastic
  • Features:Pick and Place
  • Operating Temperature:-
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Black
  • Current Rating (Amps):2A (AC/DC)
  • Voltage Rating:200V (AC/DC)

Related Products


M80-7820642

CONN HEADER VERT 6POS 2MM

M80-7820642 Datasheet
  • 1: $1.55585
  • 1008: $1.47030

0711640016

CONN HEADER VERT 11POS 2.54MM

0711640016 Datasheet
  • 1: $1.55601
  • 3264: $1.55601

892-18-020-10-001101

CONN HEADER VERT 20POS 2.54MM

892-18-020-10-001101 Datasheet
  • 1: $1.55610
  • 400: $1.39608

1-146806-5

CONN HEADER SMD 16POS 2.54MM

1-146806-5 Datasheet
  • 1: $1.55615
  • 26: $1.43885

647465-1

CONN HEADER R/A 9POS 3.96MM

647465-1 Datasheet
  • 1: $1.55620
  • 500: $1.55620

53610-G16-8LF

CONN HEADER SMD 16POS 2.54MM

  • 1: $1.55685
  • 480: $1.55685

77313-118-56LF

CONN HEADER VERT 56POS 2.54MM

77313-118-56LF Datasheet
  • 1: $1.55687
  • 300: $1.43963

850-10-020-10-001101

CONN HEADER VERT 20POS 1.27MM

850-10-020-10-001101 Datasheet
  • 1: $1.55687
  • 240: $1.55687

77313-827-44LF

CONN HEADER VERT 44POS 2.54MM

77313-827-44LF Datasheet
  • 1: $1.55687
  • 300: $1.43963

95278-408-40LF
