0681512015
Woodhead - Molex- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER VERT 20POS 2.5MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 0681512015 Datasheet
-
ECAD Model
- Share
In Stock: 188
Can ship immediately
Pricing:
- 1$1.61367
- 720$1.48628
Quote It
Technical Details
- Series:68151
- Package:Tray
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.098" (2.50mm)
- Number of Positions:20
- Number of Rows:2
- Row Spacing - Mating:0.205" (5.20mm)
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole
- Termination:Solder
- Fastening Type:Latch Lock
- Contact Length - Mating:0.276" (7.00mm)
- Contact Length - Post:0.146" (3.70mm)
- Overall Contact Length:0.547" (13.90mm)
- Insulation Height:0.776" (19.70mm)
- Contact Shape:Square
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Tin
- Contact Material:Brass
- Insulation Material:Polybutylene Terephthalate (PBT)
- Features:Mounting Flange
- Operating Temperature:-
- Ingress Protection:-
- Material Flammability Rating:-
- Insulation Color:Gray
- Current Rating (Amps):-
- Voltage Rating:-
