In Stock: 175

Can ship immediately

Pricing:
  • 1$1.69099
  • 700$1.69099

Quote It

Technical Details

  • Series:VAL-U-LOK
  • Package:Tray
  • Part Status:Active
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.165" (4.20mm)
  • Number of Positions:24
  • Number of Rows:2
  • Row Spacing - Mating:0.165" (4.20mm)
  • Number of Positions Loaded:All
  • Style:Board to Cable/Wire
  • Shrouding:Shrouded - 4 Wall
  • Mounting Type:Through Hole, Right Angle
  • Termination:Solder
  • Fastening Type:Locking Ramp
  • Contact Length - Mating:-



  • Contact Length - Post:-
  • Overall Contact Length:-
  • Insulation Height:0.402" (10.20mm)
  • Contact Shape:Square
  • Contact Finish - Mating:Tin
  • Contact Finish Thickness - Mating:-
  • Contact Finish - Post:Tin
  • Contact Material:Brass
  • Insulation Material:Polyamide (PA), Nylon
  • Features:Glow Wire Compliant
  • Operating Temperature:-40°C ~ 105°C
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-2
  • Insulation Color:White
  • Current Rating (Amps):9A
  • Voltage Rating:600VAC

Related Products


GT8E-5P-2H(10)

CONN HEADER SMD R/A 5POS 2MM

GT8E-5P-2H(10) Datasheet
  • 1: $1.69100
  • 450: $1.59600

GT8E-5P-2H(13)

CONN HEADER SMD R/A 5POS 2MM

GT8E-5P-2H(13) Datasheet
  • 1: $1.69100
  • 450: $1.63400

GT8E-6P-2H(13)

CONN HEADER SMD R/A 6POS 2MM

GT8E-6P-2H(13) Datasheet
  • 1: $1.69100
  • 450: $1.63400

141A11659X

CONN HEADER VERT 16POS 2.54MM

141A11659X Datasheet
  • 1: $1.69100
  • 440: $1.69100

1379114-3

CONN HEADER VERT 12POS 2.54MM

1379114-3 Datasheet
  • 1: $1.69101
  • 576: $1.61049

95278-801-38LF

CONN HEADER SMD 38POS 2.54MM

95278-801-38LF Datasheet
  • 1: $1.69120
  • 300: $1.56350

95278-802-38LF

CONN HEADER SMD 38POS 2.54MM

95278-802-38LF Datasheet
  • 1: $1.69120
  • 300: $1.56350

450-V3-214-00-006101

CONN HEADER VERT 14POS 2.54MM

450-V3-214-00-006101 Datasheet
  • 1: $1.69120
  • 500: $1.47728

0713491001

CONN HEADER SMD 6POS 2.54MM

0713491001 Datasheet
  • 1: $1.69134
  • 1728: $1.69134

4-794619-8
