In Stock: 147

Can ship immediately

Pricing:
  • 1$1.78133
  • 1,000$1.78133

Quote It

Technical Details

  • Series:-
  • Package:Tube
  • Part Status:Active
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.050" (1.27mm)
  • Number of Positions:34
  • Number of Rows:1
  • Row Spacing - Mating:-
  • Number of Positions Loaded:All
  • Style:Board to Board or Cable
  • Shrouding:Unshrouded
  • Mounting Type:Surface Mount
  • Termination:Solder
  • Fastening Type:Push-Pull
  • Contact Length - Mating:0.118" (3.00mm)



  • Contact Length - Post:-
  • Overall Contact Length:-
  • Insulation Height:0.039" (1.00mm)
  • Contact Shape:Square
  • Contact Finish - Mating:Gold
  • Contact Finish Thickness - Mating:Flash
  • Contact Finish - Post:Gold
  • Contact Material:Brass
  • Insulation Material:Polyamide (PA9T), Nylon 9T
  • Features:-
  • Operating Temperature:-40°C ~ 105°C
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:-
  • Current Rating (Amps):1A
  • Voltage Rating:-

Related Products


GRPB341VWTD-RC

CONN HEADER SMD 34POS 1.27MM

GRPB341VWTD-RC Datasheet
  • 1: $1.78133
  • 1000: $1.78133

0015911148

CONN HEADER SMD 14POS 2.54MM

0015911148 Datasheet
  • 1: $1.78150
  • 3240: $1.49377

890-80-038-20-002101

CONN HEADER R/A 38POS 2.54MM

890-80-038-20-002101 Datasheet
  • 1: $1.78163
  • 300: $1.64073

892-80-038-20-002101

CONN HEADER R/A 38POS 2.54MM

892-80-038-20-002101 Datasheet
  • 1: $1.78163
  • 300: $1.64073

1-2041405-0

CONN HEADER VERT 10POS 2MM

1-2041405-0 Datasheet
  • 1: $1.78174
  • 18000: $1.78174

280387-1

CONN HEADER VERT 30POS 2.54MM

280387-1 Datasheet
  • 1: $1.78183
  • 750: $1.78183

350-80-120-00-024101

CONN HEADER VERT 20POS 2.54MM

350-80-120-00-024101 Datasheet
  • 1: $1.78183
  • 400: $1.64093

0702871026

CONN HEADER VERT 56POS 2.54MM

0702871026 Datasheet
  • 1: $1.78191
  • 1400: $1.78191

77319-104-20LF

CONN HEADER R/A 20POS 2.54MM

77319-104-20LF Datasheet
  • 1: $1.78193
  • 600: $1.69628

77319-804-20LF
