800-80-034-40-001101

Preci-Dip
In Stock: 200

Can ship immediately

Pricing:
  • 1$2.01721
  • 210$2.01721

Quote It

Technical Details

  • Series:800
  • Package:Bulk
  • Part Status:Active
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.100" (2.54mm)
  • Number of Positions:34
  • Number of Rows:1
  • Row Spacing - Mating:-
  • Number of Positions Loaded:All
  • Style:Board to Board
  • Shrouding:Unshrouded
  • Mounting Type:Surface Mount, Right Angle
  • Termination:Solder
  • Fastening Type:Push-Pull
  • Contact Length - Mating:0.191" (4.85mm)



  • Contact Length - Post:-
  • Overall Contact Length:-
  • Insulation Height:0.100" (2.54mm)
  • Contact Shape:Circular
  • Contact Finish - Mating:Tin
  • Contact Finish Thickness - Mating:-
  • Contact Finish - Post:Tin
  • Contact Material:Brass
  • Insulation Material:Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
  • Features:-
  • Operating Temperature:-55°C ~ 125°C
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Black
  • Current Rating (Amps):3A
  • Voltage Rating:150VDC

Related Products


0015916146

CONN HEADER SMD 14POS 2.54MM

0015916146 Datasheet
  • 1: $2.01734
  • 5520: $2.01734

4-2842273-8

48P,2MM,SHRD HDR,DRVT,SMD,SN,TB

  • 1: $2.01744

SBH31-NBPB-D21-RA-BK

CONN HEADER R/A 42POS 1.27MM

SBH31-NBPB-D21-RA-BK Datasheet
  • 1: $2.01753
  • 1000: $2.01753

SBH31-NBPB-D21-SM-BK

CONN HEADER SMD 42POS 1.27MM

SBH31-NBPB-D21-SM-BK Datasheet
  • 1: $2.01753
  • 1000: $2.01753

SBH31-NBPB-D21-SP-BK

CONN HEADER SMD 42POS 1.27MM

SBH31-NBPB-D21-SP-BK Datasheet
  • 1: $2.01753
  • 1000: $2.01753

SBH31-NBPB-D28-ST-BK

CONN HEADER VERT 56POS 1.27MM

SBH31-NBPB-D28-ST-BK Datasheet
  • 1: $2.01753
  • 1000: $2.01753

SBH31-NBPB-D29-ST-BK

CONN HEADER VERT 58POS 1.27MM

SBH31-NBPB-D29-ST-BK Datasheet
  • 1: $2.01753
  • 1000: $ 2.01753

95278-801B38LF

CONN HEADER SMD 38POS 2.54MM

95278-801B38LF Datasheet
  • 1: $2.01761
  • 180: $1.95889

802-80-030-10-001101

CONN HEADER VERT 30POS 2.54MM

802-80-030-10-001101 Datasheet
  • 1: $2.01809
  • 408: $1.85853

75160-118-20LF
