0702800651

Woodhead - Molex
In Stock: 193

Can ship immediately

Pricing:
  • 1$2.03812
  • 1,500$2.03812

Quote It

Technical Details

  • Series:C-Grid 70280
  • Package:Bulk
  • Part Status:Active
  • Connector Type:Header, Breakaway
  • Contact Type:Male Pin
  • Pitch - Mating:0.100" (2.54mm)
  • Number of Positions:46
  • Number of Rows:2
  • Row Spacing - Mating:0.100" (2.54mm)
  • Number of Positions Loaded:All
  • Style:Board to Board or Cable
  • Shrouding:Unshrouded
  • Mounting Type:Through Hole
  • Termination:Solder
  • Fastening Type:Push-Pull
  • Contact Length - Mating:0.240" (6.10mm)



  • Contact Length - Post:0.175" (4.45mm)
  • Overall Contact Length:0.505" (12.83mm)
  • Insulation Height:0.090" (2.29mm)
  • Contact Shape:Square
  • Contact Finish - Mating:Gold
  • Contact Finish Thickness - Mating:15.0µin (0.38µm)
  • Contact Finish - Post:Tin
  • Contact Material:Copper Alloy
  • Insulation Material:Liquid Crystal Polymer (LCP), Glass Filled
  • Features:-
  • Operating Temperature:-
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Black
  • Current Rating (Amps):-
  • Voltage Rating:-

Related Products


1-281696-8

CONN HEADER VERT 18POS 2.54MM

1-281696-8 Datasheet
  • 1: $2.03850
  • 3000: $1.94400

0022283245

CONN HEADER VERT 24POS 2.54MM

0022283245 Datasheet
  • 1: $2.03854
  • 2000: $2.03854

850-10-015-40-001101

CONN HEADER SMD R/A 15POS 1.27MM

850-10-015-40-001101 Datasheet
  • 1: $2.03876
  • 250: $1.78076

3-2842273-4

34P,2MM,SHRD HDR,DRVT,SMD,SN,TB

  • 1: $2.03888

0717640216

CONN HEADER R/A 16POS 2.54MM

0717640216 Datasheet
  • 1: $2.03896
  • 2080: $2.03896

800-80-036-10-001101

CONN HEADER VERT 36POS 2.54MM

800-80-036-10-001101 Datasheet
  • 1: $2.03945
  • 200: $2.03945

0717640516

CONN HEADER R/A 16POS 2.54MM

0717640516 Datasheet
  • 1: $2.03952

67997-172H

CONN HEADER VERT 72POS 2.54MM

67997-172H Datasheet
  • 1: $2.03960
  • 100: $2.03960

67997-138HLF

CONN HEADER VERT 38POS 2.54MM

67997-138HLF Datasheet
  • 1: $2.03960
  • 200: $2.03960

GEC13SFBN-M30
