In Stock: 164

Can ship immediately

Pricing:
  • 1$2.04
  • 10$1.855
  • 25$1.742
  • 50$1.6662
  • 100$1.5904
  • 250$1.43892
  • 500$1.32532

Quote It

Technical Details

  • Series:-
  • Package:Bulk
  • Part Status:Active
  • Connector Type:Header, Breakaway
  • Contact Type:Male Pin
  • Pitch - Mating:0.100" (2.54mm)
  • Number of Positions:16
  • Number of Rows:1
  • Row Spacing - Mating:-
  • Number of Positions Loaded:All
  • Style:Board to Board or Cable
  • Shrouding:Unshrouded
  • Mounting Type:Surface Mount, Right Angle
  • Termination:Solder
  • Fastening Type:Push-Pull
  • Contact Length - Mating:0.230" (5.84mm)



  • Contact Length - Post:-
  • Overall Contact Length:-
  • Insulation Height:0.140" (3.56mm)
  • Contact Shape:Square
  • Contact Finish - Mating:Tin
  • Contact Finish Thickness - Mating:100.0µin (2.54µm)
  • Contact Finish - Post:Tin
  • Contact Material:Phosphor Bronze
  • Insulation Material:Polyamide (PA9T), Nylon 9T
  • Features:-
  • Operating Temperature:-65°C ~ 150°C
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Black
  • Current Rating (Amps):3A
  • Voltage Rating:-

Related Products


9-103323-0-14

CONN HEADER R/A 14POS 2.54MM

9-103323-0-14 Datasheet
  • 1: $2.04000
  • 10: $1.85423
  • 25: $1.74095

929834-02-22-RK

CONN HEADER VERT 22POS 2.54MM

929834-02-22-RK Datasheet
  • 1: $2.04000
  • 10: $1.85400
  • 25: $1.74080

929834-03-22-RK

CONN HEADER VERT 22POS 2.54MM

929834-03-22-RK Datasheet
  • 1: $2.04000
  • 10: $1.85400
  • 25: $1.74080

929834-04-22-RK

CONN HEADER VERT 22POS 2.54MM

929834-04-22-RK Datasheet
  • 1: $2.04000
  • 10: $1.85400
  • 25: $1.74080

929834-05-22-RK

CONN HEADER VERT 22POS 2.54MM

929834-05-22-RK Datasheet
  • 1: $2.04000
  • 10: $1.85400
  • 25: $1.74080

9-146278-0-23

CONN HEADER VERT 23POS 2.54MM

9-146278-0-23 Datasheet
  • 1: $2.04000
  • 10: $1.85553
  • 25: $1.74225

951118-7722-AR

CONN HEADER R/A 18POS 2MM

951118-7722-AR Datasheet
  • 1: $2.04000
  • 10: $1.86710
  • 25: $1.76373

961127-6404-AR

CONN HEADER VERT 27POS 2.54MM

961127-6404-AR Datasheet
  • 1: $2.04000
  • 10: $1.86710
  • 25: $1.76373

961127-6804-AR
