0901220770

Woodhead - Molex
In Stock: 106

Can ship immediately

Pricing:
  • 1$2.60685

Quote It

Technical Details

  • Series:C-Grid III 90122
  • Package:Bulk
  • Part Status:Active
  • Connector Type:Header, Breakaway
  • Contact Type:Male Pin
  • Pitch - Mating:0.100" (2.54mm)
  • Number of Positions:20
  • Number of Rows:2
  • Row Spacing - Mating:0.100" (2.54mm)
  • Number of Positions Loaded:All
  • Style:Board to Board or Cable
  • Shrouding:Unshrouded
  • Mounting Type:Through Hole, Right Angle
  • Termination:Solder
  • Fastening Type:Push-Pull
  • Contact Length - Mating:0.266" (6.75mm)



  • Contact Length - Post:0.114" (2.90mm)
  • Overall Contact Length:-
  • Insulation Height:0.242" (6.14mm)
  • Contact Shape:Square
  • Contact Finish - Mating:Gold
  • Contact Finish Thickness - Mating:15.0µin (0.38µm)
  • Contact Finish - Post:Tin
  • Contact Material:Brass
  • Insulation Material:Polyester, Glass Filled
  • Features:-
  • Operating Temperature:-
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Black
  • Current Rating (Amps):-
  • Voltage Rating:-

Related Products


350-80-134-00-013101

CONN HEADER VERT 34POS 2.54MM

350-80-134-00-013101 Datasheet
  • 1: $2.60718
  • 220: $2.40118

450-80-234-00-013101

CONN HEADER VERT 34POS 2.54MM

450-80-234-00-013101 Datasheet
  • 1: $2.60718
  • 220: $2.40118

0877602617

CONN HEADER R/A 26POS 2MM

0877602617 Datasheet
  • 1: $2.60783
  • 2400: $2.42798

350-80-151-01-714101

CONN HEADER VERT 26POS 5.08MM

350-80-151-01-714101 Datasheet
  • 1: $2.60800
  • 220: $2.40200

892-70-058-20-001101

CONN HEADER R/A 58POS 2.54MM

892-70-058-20-001101 Datasheet
  • 1: $2.60800
  • 220: $2.36418

0348975120

CONN HEADER SMD R/A 12POS 2MM

0348975120 Datasheet
  • 1: $2.60834
  • 1700: $2.60834

0348975121

CONN HEADER SMD R/A 12POS 2MM

0348975121 Datasheet
  • 1: $2.60834
  • 1700: $2.60834

0348975122

CONN HEADER SMD R/A 12POS 2MM

  • 1: $2.60834
  • 1700: $2.60834

860-10-033-10-001101

CONN HEADER VERT 33POS 1MM

860-10-033-10-001101 Datasheet
  • 1: $2.60869
  • 130: $2.60869

93690-102-50LF
