929400-01-29

3M
In Stock: 160

Can ship immediately

Pricing:
  • 1$2.61
  • 10$2.368
  • 25$2.2232
  • 50$2.1266
  • 100$2.03
  • 250$1.83668
  • 500$1.69168

Quote It

Technical Details

  • Series:929
  • Package:Bulk
  • Part Status:Active
  • Connector Type:Header, Breakaway
  • Contact Type:Male Pin
  • Pitch - Mating:0.100" (2.54mm)
  • Number of Positions:29
  • Number of Rows:1
  • Row Spacing - Mating:-
  • Number of Positions Loaded:All
  • Style:Board to Board
  • Shrouding:Unshrouded
  • Mounting Type:Through Hole
  • Termination:Solder
  • Fastening Type:Push-Pull
  • Contact Length - Mating:0.295" (7.49mm)



  • Contact Length - Post:0.130" (3.30mm)
  • Overall Contact Length:0.535" (13.59mm)
  • Insulation Height:0.110" (2.79mm)
  • Contact Shape:Square
  • Contact Finish - Mating:Tin-Lead
  • Contact Finish Thickness - Mating:100.0µin (2.54µm)
  • Contact Finish - Post:-
  • Contact Material:Copper Alloy
  • Insulation Material:Polybutylene Terephthalate (PBT), Polyester, Glass Filled
  • Features:-
  • Operating Temperature:-40°C ~ 105°C
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Black
  • Current Rating (Amps):2.5A
  • Voltage Rating:-

Related Products


PEC28SAEN

CONN HEADER VERT 28POS 2.54MM

PEC28SAEN Datasheet
  • 1: $2.61000
  • 10: $2.50900
  • 25: $2.29960

PBC19SAGN

CONN HEADER VERT 19POS 2.54MM

PBC19SAGN Datasheet
  • 1: $2.61000
  • 10: $2.50800
  • 25: $2.29920

PEC32SBBN

CONN HEADER R/A 32POS 2.54MM

PEC32SBBN Datasheet
  • 1: $2.61000
  • 10: $2.50900
  • 25: $2.29960

PEC21SBCN

CONN HEADER R/A 21POS 2.54MM

PEC21SBCN Datasheet
  • 1: $2.61000
  • 10: $2.36700
  • 25: $2.22200

PEC32SGAN

CONN HEADER R/A 32POS 2.54MM

PEC32SGAN Datasheet
  • 1: $2.61000
  • 10: $2.50900
  • 25: $2.29960

PBC34SBAN

CONN HEADER R/A 34POS 2.54MM

PBC34SBAN Datasheet
  • 1: $2.61000
  • 10: $2.50200
  • 25: $2.29400

PBC25SGAN

CONN HEADER R/A 25POS 2.54MM

PBC25SGAN Datasheet
  • 1: $2.61000
  • 10: $2.36800
  • 25: $2.22320

PBC27SGAN

CONN HEADER R/A 27POS 2.54MM

PBC27SGAN Datasheet
  • 1: $2.61000
  • 10: $2.50600
  • 25: $2.29680

PEC13DAEN

CONN HEADER VERT 26POS 2.54MM

PEC13DAEN Datasheet
  • 1: $2.61000
  • 10: $2.36800
  • 25: $2.22240

PEC25DFAN
