In Stock: 113

Can ship immediately

Pricing:
  • 1$2.7246
  • 650$2.4078

Quote It

Technical Details

  • Series:AMP-Latch
  • Package:Tray
  • Part Status:Active
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.100" (2.54mm)
  • Number of Positions:30
  • Number of Rows:2
  • Row Spacing - Mating:0.100" (2.54mm)
  • Number of Positions Loaded:All
  • Style:Board to Cable/Wire
  • Shrouding:Shrouded - 4 Wall
  • Mounting Type:Through Hole
  • Termination:Solder
  • Fastening Type:Push-Pull
  • Contact Length - Mating:0.240" (6.10mm)



  • Contact Length - Post:0.110" (2.79mm)
  • Overall Contact Length:0.639" (16.23mm)
  • Insulation Height:0.549" (13.94mm)
  • Contact Shape:Square
  • Contact Finish - Mating:Gold or Gold-Palladium
  • Contact Finish Thickness - Mating:30.0µin (0.76µm)
  • Contact Finish - Post:Tin
  • Contact Material:-
  • Insulation Material:-
  • Features:Keying Slot, Mounting Flange
  • Operating Temperature:-65°C ~ 105°C
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Blue
  • Current Rating (Amps):1A per Contact
  • Voltage Rating:-

Related Products


350-10-133-01-609101

CONN HEADER VERT 17POS 5.08MM

350-10-133-01-609101 Datasheet
  • 1: $2.72482
  • 220: $2.37995

GRPB262VWQP-RC

CONN HEADER SMD 52POS 1.27MM

GRPB262VWQP-RC Datasheet
  • 1: $2.72484
  • 1000: $2.72484

GRPB262VWQS-RC

CONN HEADER SMD 52POS 1.27MM

GRPB262VWQS-RC Datasheet
  • 1: $2.72484
  • 1000: $2.72484

1054312205

NANO-FIT HDR SMT VT SGL 5CKT 15A

  • 1: $2.72492

890-18-034-10-001101

CONN HEADER VERT 34POS 2.54MM

890-18-034-10-001101 Datasheet
  • 1: $2.72500
  • 210: $2.44462

892-18-034-10-001101

CONN HEADER VERT 34POS 2.54MM

892-18-034-10-001101 Datasheet
  • 1: $2.72500
  • 400: $2.13903

15150302601000

HAR-FLEX ANGLED MALE, 30PIN, PL1

  • 1: $2.72532

800-80-037-10-002101

CONN HEADER VERT 37POS 2.54MM

800-80-037-10-002101 Datasheet
  • 1: $2.72540
  • 400: $2.19593

850-10-017-30-001101

CONN HEADER SMD 17POS 1.27MM

850-10-017-30-001101 Datasheet
  • 1: $2.72559
  • 220: $2.38077

0901361220
