804-V3-015-6B-002101

Preci-Dip
In Stock: 158

Can ship immediately

Pricing:
  • 1$2.774
  • 210$2.42276

Quote It

Technical Details

  • Series:802
  • Package:Bulk
  • Part Status:Active
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.100" (2.54mm)
  • Number of Positions:15
  • Number of Rows:3
  • Row Spacing - Mating:0.100" (2.54mm)
  • Number of Positions Loaded:All
  • Style:Board to Board
  • Shrouding:Unshrouded
  • Mounting Type:Through Hole
  • Termination:Press-Fit, Solder
  • Fastening Type:Push-Pull
  • Contact Length - Mating:0.141" (3.60mm)



  • Contact Length - Post:0.110" (2.79mm)
  • Overall Contact Length:0.378" (9.60mm)
  • Insulation Height:0.272" (6.91mm)
  • Contact Shape:Circular
  • Contact Finish - Mating:Gold
  • Contact Finish Thickness - Mating:29.5µin (0.75µm)
  • Contact Finish - Post:Tin
  • Contact Material:Bronze
  • Insulation Material:Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
  • Features:-
  • Operating Temperature:-55°C ~ 125°C
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Black
  • Current Rating (Amps):3A
  • Voltage Rating:150VDC

Related Products


350-10-123-00-018101

CONN HEADER VERT 23POS 2.54MM

350-10-123-00-018101 Datasheet
  • 1: $2.77438
  • 210: $2.42319

832-80-040-10-001101

CONN HEADER VERT 40POS 2MM

832-80-040-10-001101 Datasheet
  • 1: $2.77444
  • 250: $2.55512

4-2842271-4

44P,2MM,SHRD HDR,DRRT,0.38AU,TR

  • 1: $2.77458

0010883241

CONN HEADER R/A 24POS 2.54MM

  • 1: $2.77522

64991-G12-4RLF

CONN HEADER VERT 24POS 2.54MM

64991-G12-4RLF Datasheet
  • 1: $2.77578
  • 2070: $2.77578

830-10-020-40-001101

CONN HEADER SMD R/A 20POS 2MM

830-10-020-40-001101 Datasheet
  • 1: $2.77662
  • 210: $2.42524

20021621-00034C4LF

HD EJECT SMT

  • 1: $2.77725

57102-G08-15LF

CONN HEADER VERT 30POS 2MM

57102-G08-15LF Datasheet
  • 1: $2.77746
  • 500: $2.56820

77313-162-40LF
