In Stock: 193

Can ship immediately

Pricing:
  • 1$2.93
  • 10$2.808
  • 25$2.574
  • 50$2.457
  • 100$2.34
  • 250$2.04752
  • 500$1.989

Quote It

Technical Details

  • Series:-
  • Package:Bulk
  • Part Status:Active
  • Connector Type:Header, Breakaway
  • Contact Type:Male Pin
  • Pitch - Mating:0.100" (2.54mm)
  • Number of Positions:36
  • Number of Rows:2
  • Row Spacing - Mating:0.100" (2.54mm)
  • Number of Positions Loaded:All
  • Style:Board to Board or Cable
  • Shrouding:Unshrouded
  • Mounting Type:Through Hole, Right Angle
  • Termination:Solder
  • Fastening Type:Push-Pull
  • Contact Length - Mating:0.230" (5.84mm)



  • Contact Length - Post:0.200" (5.08mm)
  • Overall Contact Length:-
  • Insulation Height:0.240" (6.10mm)
  • Contact Shape:Square
  • Contact Finish - Mating:Tin
  • Contact Finish Thickness - Mating:100.0µin (2.54µm)
  • Contact Finish - Post:Tin
  • Contact Material:Phosphor Bronze
  • Insulation Material:Polybutylene Terephthalate (PBT)
  • Features:-
  • Operating Temperature:-65°C ~ 125°C
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Black
  • Current Rating (Amps):3A
  • Voltage Rating:-

Related Products


GBC18SBSN-M89

CONN HEADER SMD R/A 18POS 2.54MM

GBC18SBSN-M89 Datasheet
  • 1: $2.93000
  • 10: $2.80800
  • 25: $2.57400

929838-02-25-RK

CONN HEADER R/A 50POS 2.54MM

929838-02-25-RK Datasheet
  • 1: $2.93000
  • 10: $2.81600
  • 25: $2.58120

929838-04-25-RK

CONN HEADER R/A 50POS 2.54MM

929838-04-25-RK Datasheet
  • 1: $2.93000
  • 10: $2.81600
  • 25: $2.58120

9-103324-0-18

CONN HEADER R/A 36POS 2.54MM

9-103324-0-18 Datasheet
  • 1: $2.93000
  • 10: $2.80783
  • 25: $2.57408

9-146258-0-26

CONN HEADER VERT 52POS 2.54MM

9-146258-0-26 Datasheet
  • 1: $2.93000
  • 10: $2.80783
  • 25: $2.57364

9-146254-0-22

CONN HEADER VERT 44POS 2.54MM

  • 1: $2.93000
  • 10: $2.80783
  • 25: $2.57408

961242-6404-AR
